Description
Manufacturing Excellence: Uncompromising Specifications
Our commitment to durability is built into every dimension of our Barrel Reamers. We refuse to compromise on the materials that ensure the reamer’s performance and lifespan.
- Extreme Size Range & Core Strength
- Size Range: We manufacture all sizes from 10 inches up to 72 inches in diameter, making us the single source for your entire fleet’s reaming needs.
- Premium Shaft: The central shaft, the backbone of the reamer, is forged from 4145 Alloy Steel.
- Rugged Barrel Plate: The main body and wings are constructed using heavy-duty steel plate ranging from 12 mm to 16 mm in thickness.
- Cutting, Stabilizing, and Hydraulics (H3)
| Feature | Technical Specification | Benefit & Versatility |
|---|---|---|
| Dual-Action Cutters | API Threads & Back Cutters. | Useable for back or forward reaming; ideal for cleaning pre-reamed holes or stacking with a fly cutter/hole opener. |
| Cutting Power | Replaceable Bullet Bits (Premium Carbide). | Tungsten Carbide tips grind through tough ground conditions (sand, loam, cobble, stiff clay) and are easily replaced in the field. |
| Hydraulics | High-Quality SS Nozzles. | Equipped with Stainless Steel (SS) nozzle holders and jets for mud ports, allowing operators to easily interchange nozzles to vary jet sizes and pressures for optimal cuttings evacuation. |
| Stacking Capability | Robust thread design. | Can be used for stacking with other reamers to achieve multi-stage hole enlargement in a single pass. |
